TERRY LIFTS
Melody 1
Melody 1 Platform Lift
The Melody 1 is a versatile platform lift for wheelchair access in both domestic and public settings, for low-rise access.
Highlights/features:
Internal platform size standard ~ 900 mm × 1400 mm; travels up to 1000 mm (1 m).
Highlights/features:
Can be used indoors or outdoors, free-standing (no support tower), minimal pit or ramp required.
Highlights/features:
250 kg load capacity, battery backup in case of power failure, hydraulic scissor drive, smooth and quiet.
Melody 3
Melody 3 Platform Lift
The Melody 3 is a vertical platform lift designed for wheelchair users (and attendant/carer if needed) that can be installed both indoors and outdoors.
Highlights/features:
Provides travel of up to 3 metres (for public access the max is 2 m) making it suitable for low-rise vertical access where stairs or steps would otherwise limit entry.
Two standard platform sizes: 900 mm × 1400 mm and 1100 mm × 1400 mm, offering flexibility depending on space and user needs.
High load capacity: up to 500 kg for travel up to 2 m, or up to 440 kg for travel up to 3 m, meaning most manual or powered wheelchairs plus a carer can be accommodated.
Two standard platform sizes: 900 mm × 1400 mm and 1100 mm × 1400 mm, offering flexibility depending on space and user needs.
High load capacity: up to 500 kg for travel up to 2 m, or up to 440 kg for travel up to 3 m, meaning most manual or powered wheelchairs plus a carer can be accommodated.
Highlights/features:
Design advantages: No side-support mast is required, making the installation less obtrusive and better suited to integrating into the building fabric.
Built-in access ramp (so no pit required) and quick installation — minimal structural building work required.
Safety and convenience features: battery back-up for emergency lowering, sensitive safety surfaces to protect against entrapment, interlocking/optional powered gates for easy access/egress.
Built-in access ramp (so no pit required) and quick installation — minimal structural building work required.
Safety and convenience features: battery back-up for emergency lowering, sensitive safety surfaces to protect against entrapment, interlocking/optional powered gates for easy access/egress.
Highlights/features:
Suitable for domestic and public/commercial use; complies with relevant standards
(e.g., BS 6440:2011, Machinery Directive) and supports compliance with accessibility requirements (e.g., Equality Act 2010).
Customisation options: wider platform size, special colour finishes, stainless-steel kit, dual-car controls, various flooring and illumination options.
(e.g., BS 6440:2011, Machinery Directive) and supports compliance with accessibility requirements (e.g., Equality Act 2010).
Customisation options: wider platform size, special colour finishes, stainless-steel kit, dual-car controls, various flooring and illumination options.
